PRIODOOR RTX-UH
Inspection Opening Closure with wall
With side panels
For surface mounting on solid walls
For electrical distribution boards in escape routes
PRIODOOR RTX-UH
Universal, tightly closing inspection opening closure with side wall elements, for installation on solid walls. Available in single- and double-leaf versions, this closure is suitable for small and large-scale compartmentalisation of metering equipment and distribution boards in escape routes. The inspection opening closure is tightly sealed all round and offers a fire resistance for 30/90 minutes.
Inspection opening closure with side wall elements PRIODOOR RTX–UH
Double–leaf access door with side panels, surface–mounted in the emergency exit
Function
- 30/90 minutes fire resistance, fire retardant/fire resistant
- EI 30 i→o, EI 90 i→o classification
- Smoke protection
- Leak-proof closing
Construction
- Inspection opening closure with high mechanical strength
- Single- and double-leaf versions
- Four-sided frame for wall mounting (max. depth 300 mm)*
- Three-sided frame for installation on a subfloor (in combination with PRIOWALL and PRIOCEIL)
- Circumferential block frame, 43 mm wide
- Perimeter smoke and fire protection seals, self-expanding in the event of a fire
- Door rebated into the frame, opening angle approx. 180°
- Mortise lock, locking with profile half-cylinder
- Bolt lock without latch
- Door hinge DIN right, optionally DIN left
- Door detachable
- Door hinges in stainless steel
* With additional declaration of conformity
Material
Material characteristic
- Non-combustible board with surface coating, classification A2 – s1, d0
- Standard laminate surface
- Colour light grey, similar to RAL 7035, edges and bevels in different colour
- Frame width from 43 mm to 100 mm*
- Many PRIORIT surfaces possible
- Technical ventilation on request
- With fire resistant penetration seal at top and/or bottom on request
- Door lock cylinder rosette on one side
- Single cylinder 30/10, senate closure, incl. 2 cruciform keys 75 mm
- Single cylinder keyed-differently without rosette
* Valid from an inside width/inside height of the PRIODOOR RTX inspection opening closure of 314 mm.
